Portable Submersible Pump
>
Easy To Carry Submersible Slurry Pump 70m³/H 18m 5.5kw 1hp-10hp For Clean Water Sewage Flood Removal And Agricultural

Easy To Carry Submersible Slurry Pump 70m³/H 18m 5.5kw 1hp-10hp For Clean Water Sewage Flood Removal And Agricultural

Brand Name: ATPUMP
Model Number: BQS70-18-5.5
MOQ: 1
Price: USD 219-1999 / set
Packaging Details: Plywood case
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Detail Information
Place of Origin:
China
Certification:
CE、ISO 9001、ISO 14001、ISO45001
Rated Flow:
70 M³/h
Rated Head:
18 M
Rated Power:
5.5 KW
Synchronous:
3000 R/min
Outlet Diameter:
100 Mm
Voltage:
380/660 Or 660/1140 V (Customizable)
Medium Temperature:
≤40℃
PH:
4-10
Material:
Nodular Cast Iron, SS304, SS316, SS316L, Duplex Stainless Steel,high Chromium Alloy
Color:
RAL5005 Or As Your Requirements
Medium Density:
≤1100 Kg/m3
Submergence:
≤20m
Cable Length(Standard):
5 M
Cable Standards:
MT818.5-2009 Flame-retardant Cable
Customizable:
Yes
Insulation Rating:
F/H
Frequency:
50Hz / 60Hz
Pump Type:
Submersible Electric Pump
Drive:
Electric Pump
Supply Ability:
100000 sets per year
Highlight:

70m³/h portable submersible pump

,

70m³/h explosion proof submersible pump

,

18m portable submersible pump

Product Description

70m³/h 18m 5.5kw 1hp-10hp Easy-To-Carry submersible slurry pump Submersible Portable Pump For Clean Water, Sewage,Flood Removal And Agricultural UseEasy To Carry Submersible Slurry Pump 70m³/H 18m 5.5kw 1hp-10hp For Clean Water  Sewage Flood Removal And Agricultural 0

The BQS70-18-5.5 is engineered with a focus on optimizing flow rates while maintaining reliability and safety. Its hydraulic system is designed to handle large volumes of fluid efficiently, minimizing energy consumption and reducing the risk of blockages, making it ideal for applications involving fluids with moderate levels of solid particles. The pump's mechanical seals are built to withstand harsh conditions, ensuring leak-proof operation and extending the service life even under continuous use. Installation and maintenance are simplified by its compact design, which fits well into confined spaces without compromising performance. For enhanced operational efficiency and reduced downtime, users can opt for an integrated smart monitoring system that provides real-time data on essential parameters like temperature, pressure, and vibration. This feature supports predictive maintenance, helping to keep the pump running smoothly and reliably over time. With its robust construction and advanced features, the BQS70-18-5.5 is an excellent choice for demanding environments where safety and performance are critical.

Easy To Carry Submersible Slurry Pump 70m³/H 18m 5.5kw 1hp-10hp For Clean Water  Sewage Flood Removal And Agricultural 1
Easy To Carry Submersible Slurry Pump 70m³/H 18m 5.5kw 1hp-10hp For Clean Water  Sewage Flood Removal And Agricultural 2
Easy To Carry Submersible Slurry Pump 70m³/H 18m 5.5kw 1hp-10hp For Clean Water  Sewage Flood Removal And Agricultural 3
Easy To Carry Submersible Slurry Pump 70m³/H 18m 5.5kw 1hp-10hp For Clean Water  Sewage Flood Removal And Agricultural 4

  • Voltage: 380/660V,660/1140V,400V,440V,460V, customizable options are available.
  • Medium: Temperature not exceeding 40°C, PH 4-10, medium density ≤ 1100 kg/m³.(Customizable for special requirements).
  • Submersion depth: ≤20m.
  • Materials suitable for highly corrosive fluids can be customized.
  • The diameter of solid particles in the medium should comply with the regulations of MT/T671-2005. Please specify any special requirements when ordering.
  • MT818.5-2009 flame-retardant cable for coal mines.

Easy To Carry Submersible Slurry Pump 70m³/H 18m 5.5kw 1hp-10hp For Clean Water  Sewage Flood Removal And Agricultural 5

  • Applicable to places with explosion hazards such as methane (gas), coal dust, etc.
  • It can transport mixed sewage containing insoluble substances such as silt, coal slime, coal slag, and fiber.
  • Applicable to buildings, hospitals, residential areas, municipal engineering, road construction, factory sewage discharge, etc., and discharges wastewater, rainwater and sewage containing solid particles and long fibers.
  • The material of the product can be changed to cope with the situation of conveying corrosive liquids.

Easy To Carry Submersible Slurry Pump 70m³/H 18m 5.5kw 1hp-10hp For Clean Water  Sewage Flood Removal And Agricultural 6

Easy To Carry Submersible Slurry Pump 70m³/H 18m 5.5kw 1hp-10hp For Clean Water  Sewage Flood Removal And Agricultural 7

Easy To Carry Submersible Slurry Pump 70m³/H 18m 5.5kw 1hp-10hp For Clean Water  Sewage Flood Removal And Agricultural 8Easy To Carry Submersible Slurry Pump 70m³/H 18m 5.5kw 1hp-10hp For Clean Water  Sewage Flood Removal And Agricultural 9

Easy To Carry Submersible Slurry Pump 70m³/H 18m 5.5kw 1hp-10hp For Clean Water  Sewage Flood Removal And Agricultural 10

Easy To Carry Submersible Slurry Pump 70m³/H 18m 5.5kw 1hp-10hp For Clean Water  Sewage Flood Removal And Agricultural 11

Easy To Carry Submersible Slurry Pump 70m³/H 18m 5.5kw 1hp-10hp For Clean Water  Sewage Flood Removal And Agricultural 12

FAQ


Q1: What if the model I need is not in your catalog?
A: We can accept customization, including but not limited to flow rate, head, material, function, etc. You only need to tell me the relevant information, and we have a professional technical team to provide you with plans and drawings.



Q2: How do I place an order?
A:
Send us an inguiry - Tell us your needs and usage scenarios - Customize drawings and samples - Discuss details - Modify and confirm - Sign a contract/Deposit - Mass production - Final payment and delivery - Further cooperation.



Q3: How to transport?
A: We have a variety of transportation options. If there is a port in your area, sea transportation is an economical choice. If you are in a hurry to use it, we can ship it by air for you. If you don’t have your own freight forwarder, we can contract the relevant work from departure to arrival at the destination port.



Q4: Why choose you?
A: ATPUMP has been working with top domestic experts to develop and upgrade products since 2005. So far, it has participated in thousands of projects and cooperated with many major domestic projects. In China, we are the only one that can manufacture 1.5-4500kW products. We are the first choice for many domestic companies and projects, which proves that we have sufficient technical strength and quality support.



Q5: What guarantees do I have when buying your products?

A: Our after-sales service implements the "2-4-24 standard". 2-hour response, telephone remote guidance within 4 hours, and solutions within 24 hours. If there is a need, we can provide door-to-door after-sales service.



Q6: I want to be your dealer, what are the conditions?

A: No problem at all, dear, it is recommended that you purchase a sample first to try it out. If you have any special needs and modification suggestions, our technical team is at your service at any time. Looking forward to our further cooperation!
