Submersible Drainage Pump
>
High Performance Reliable Submersible Drainage Pump 132kW For Swift And Comprehensive Water Evacuation

High Performance Reliable Submersible Drainage Pump 132kW For Swift And Comprehensive Water Evacuation

Brand Name: ATPUMP
Model Number: BQS132kw
MOQ: 1
Price: USD 450-12000/ set
Packaging Details: Plywood case
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Detail Information
Place of Origin:
China
Certification:
CE、ISO 9001、ISO 14001、ISO45001
Rated Voltage:
380/660V,660/1140V,400V,440V,460V, Customizable
Synchronous Speed:
3000/1500 R/min
Medium Temperature:
≤ 40℃
PH:
2 -10
Medium Density:
≤ 1100 Kg/m³
Submergence:
≤ 20m
Cable Length(Standard):
15m
Cable Standards:
MT818.5-2009 Flame-retardant Cable
Customizable:
Yes
Insulation Rating:
F/H
Frequency:
50Hz / 60Hz
Pump Type:
Submersible Electric Pump
Drive:
Electric Pump
Material:
Ductile Iron QT600-3, SS304, SS316, SS316L, Duplex Stainless Steel,high Chromium Alloy
Power:
1.5kw-315kw
Rated Flow:
60m³/h
Rated Head:
300m
Rated Current:
253.23/146.21 Or 146.21/84.41 A
Supply Ability:
100000 sets per year
Highlight:

reliable submersible drainage pump

,

submersible drainage pump 132kw

,

reliable submersible drainage sump pump

Product Description

132kW High - Performance Reliable Submersible Drainage Pumps: For Swift and Comprehensive Water Evacuation

High Performance Reliable Submersible Drainage Pump 132kW For Swift And Comprehensive Water Evacuation 0



Working Environment and Conditions



The pump is meticulously engineered to operate seamlessly and continuously under the following well - defined conditions:



1. Power Supply



The power supply for this pump is specified by a rated frequency of 50Hz and a rated voltage of three - phase alternating current (AC), with available voltage configurations of 380V, 660V, or 1140V. To guarantee optimal pump performance, customers are duty - bound to confirm the precise voltage value at the moment of placing an order.


2. Submersion Depth



This pump is designed with the versatility to function effectively in two distinct scenarios. It can operate in shallow surface water or be submerged to a maximum depth of 5m. This design flexibility enables its application across a diverse array of water - related settings, catering to various operational requirements.


3. Temperature



Concerning temperature, the temperature of the medium being pumped must not exceed 40°C. Concurrently, the working environment temperature should be maintained within the range of 0°C to 40°C. These temperature constraints are of utmost importance as they are critical for ensuring the reliable and long - term operation of the pump.


4. pH Value



The pH value of the medium is required to lie within the range of 6 - 8. Maintaining this specific pH range is essential as it plays a pivotal role in preventing corrosion and safeguarding the integrity of the pump's components during operation.


5. Solid Impurities and Medium Density



The volume fraction of solid impurities present in the water should not exceed 2%. Moreover, the density of the medium must be less than 1.02 x 10³ kg/m³. These parameters are of vital significance in ensuring the smooth operation of the pump and preventing any potential damage to its internal mechanisms.


6. Solid Particle Size



The size of solid particles in the water is restricted such that it does not exceed 50% of the minimum cross - sectional size of the pump's flow passage. This limitation serves as a safeguard, protecting the pump from potential blockages and ensuring efficient fluid flow through the system.



High Performance Reliable Submersible Drainage Pump 132kW For Swift And Comprehensive Water Evacuation 1

High Performance Reliable Submersible Drainage Pump 132kW For Swift And Comprehensive Water Evacuation 2



No.



Model



Rated flow

(m³/h)



Rated head

(m)



Rated power

(kW)



Rated voltage

(V)


Synchronous
speed
(r/min)

Efficiency
(%)



Outlet diameter

(mm)

1
BQS60-300/4-132/N
60 300 132
380/660 or 660/1140 or as your request
3000 43.74 100
2 BQS100-200/2-132/N 100 200 132
380/660 or 660/1140 or as your request
3000 46.55 100
3
BQS150-150/2-132/N
150 150 132
380/660 or 660/1140 or as your request
3000 51.22 150
4
BQS240-120/2-132/N
240 120 132
380/660 or 660/1140 or as your request
3000 56.41 150
5
BQS300-90-132/N
300 90 132
380/660 or 660/1140 or as your request
3000 57.73 150
6 BQS700-40-132 700 40 132
380/660 or 660/1140 or as your request
1500 61.9 200
7 BQS800-35-132 800 35 132 380/660 or 660/1140 or as your request 1500 62.6 250

High Performance Reliable Submersible Drainage Pump 132kW For Swift And Comprehensive Water Evacuation 3

High Performance Reliable Submersible Drainage Pump 132kW For Swift And Comprehensive Water Evacuation 4

This product is painstakingly engineered to meet the exacting demands of hazardous environments where methane (popularly known as gas) and coal - dust pose substantial explosion risks. It showcases unparalleled expertise in managing sewage that consists of a sophisticated blend of insoluble solid components, including sediment, coal slime, cinders, and fibrous materials.



Moreover, its application domain is extensive, spanning the conveyance of rainwater and sewage laden with solid particles across a wide gamut of settings. These settings include construction sites, hospitals, residential neighborhoods, municipal engineering projects, road construction endeavors, and factory wastewater treatment facilities.



Featuring an expansive array of models, the power of these products ranges from 2.2kW to 315kW. The flow rate varies from 10m³/h to 2500m³/h, and the head extends from 7m to 700m. All products are ingeniously designed to operate across the entire head range without incurring the risk of overload at any point within this spectrum. This design ensures consistent and dependable performance under diverse operational conditions, making it a reliable choice for various applications.



High Performance Reliable Submersible Drainage Pump 132kW For Swift And Comprehensive Water Evacuation 5

High Performance Reliable Submersible Drainage Pump 132kW For Swift And Comprehensive Water Evacuation 6

High Performance Reliable Submersible Drainage Pump 132kW For Swift And Comprehensive Water Evacuation 7

Standard Pump Construction and Features


Standard pumps are masterfully crafted from QT600 - 3 nodular cast iron. The deliberate selection of this material endows the pump with outstanding long - term durability. This enables the pump to endure the strenuous demands of continuous operation over extended periods, solidifying its reputation for resilience. The robust build of the pump is a testament to its capacity to withstand the rigors of diverse working conditions without sacrificing performance.


Mechanical Seals


The mechanical seals incorporated within these pumps are ingeniously engineered to offer high - pressure resistance. This attribute not only enhances the pump's operational performance but also allows for greater submergence depths. Consequently, the pump can function efficiently across a wide variety of challenging applications, adapting effortlessly to the unique requirements of each task.


Cooling Jacket Design


These pumps are outfitted with a cooling jacket, a design innovation that enables operation without full submersion in the medium. With the flow components situated beneath the motor, the motor is water - cooled during operation. This forward - thinking design not only extends the motor's lifespan but also ensures optimal functionality even at low water levels. It represents a significant leap in pump design, bolstering both efficiency and reliability.


Self - Cooling Motor


The motor is cooled by the very water it pumps, a self - contained cooling mechanism that guarantees dependable and safe operation under normal working conditions. This self - cooling system is a key differentiator, eliminating the need for supplementary cooling mechanisms and minimizing the risk of overheating.


Top - Outlet Design


The pump's top - outlet design provides a distinct advantage in terms of space utilization. It offers a more space - efficient solution, streamlining the installation process and enabling seamless integration into various systems. This design choice is particularly advantageous in applications where space is limited, providing greater flexibility in system design.


Thermal Protection for Motors


For added protection, sealed motors come with an optional built - in thermal protection feature. This safeguard serves as a critical line of defense, preventing overheating and potential damage to the motor. By maintaining the motor's temperature within safe parameters, it ensures the motor's long - term reliability and consistent performance.


Sealed Pressure Relief Port


A sealed pressure relief port is strategically located to prevent the pumping pressure from directly impacting the shaft seal. This design element not only protects the shaft seal but also contributes to the overall longevity and performance of the pump. By alleviating excess pressure, it reduces wear and tear on the shaft seal, ensuring its continued efficacy over time.



High Performance Reliable Submersible Drainage Pump 132kW For Swift And Comprehensive Water Evacuation 8

High Performance Reliable Submersible Drainage Pump 132kW For Swift And Comprehensive Water Evacuation 9

High Performance Reliable Submersible Drainage Pump 132kW For Swift And Comprehensive Water Evacuation 10

High Performance Reliable Submersible Drainage Pump 132kW For Swift And Comprehensive Water Evacuation 11



Q6: I want to be your dealer, what are the conditions?

A: No problem at all, dear, it is recommended that you purchase a sample first to try it out. If you have any special needs and modification suggestions, our technical team is at your service at any time. Looking forward to our further cooperation!
